Työpaino
34 700 kg
Teho
161 kW
Moottori
Cummins B6.7
Product Features
- Cummins B6.7 engine delivers 5% more torque- 20% increase on slew torque
- Heavier duty undercarriage with bilateral supported upper rollers
- Electro-hydraulic control technology- Boom float technology- Attachment flow and pressure control
- 360 degree camera- Ground level daily inspection
- F-Series Ergonomic cab design- Intuitive operator interfaces & control
Specification
Download a brochure933F
Operating weight
34300 kg
Engine power
161 kW @ 2200 rpm
Std. Bucket capacity
1.4 m³
Travel speed(High)
5.5 km/h
Travel speed(Low)
3.0 km/h
Maximum swing speed
10.3 rpm
Arm breakout force
149 kN
Bucket breakout force
203 kN
Shipping length
10650 mm
Shipping width
3190 mm
Shipping height
3525 mm
Track shoe width (std)
600 mm
Boom
6200 mm
Arm
3050 mm
Digging reach
10653 mm
Digging depth
7300 mm
Vertical wall digging depth
6216 mm
Cutting height
10300 mm
Dumping height
7265 mm
Minimum front swing radius
4040 mm
Model
Cummins B6.7
Emission
Stage V/ Tier 4F
System maximum flow
2×266 L/min (2x70 gal/min)
System pressure
34.3 MPa
